MECO Series 1000 Medium Duty Single-Sided Cantilever Uprights with Base

Imagem

MECO Series 1000 Medium Duty Single-Sided Cantilever Uprights with Base

These are individual uprights and bases for the MECO Series 1000 Medium Duty Cantilever Rack system. Price includes the upright column and base only. Cantilever arms and brace sets are sold separately and must be ordered to complete a functional rack section. This page is for buyers who are adding uprights to an existing Series 1000 installation or configuring a custom layout rather than purchasing a complete starter or add-on unit.

Uprights are available in five heights (6', 7', 8', 10', 12') and three base lengths per height, producing 15 models. The base length determines which arm lengths are compatible. Series 1000 uprights are compatible only with Series 1000 arms and brace sets -- they are not interchangeable with any other MECO rack series.

Choosing the Right Upright Model:

The model number encodes the height and base length. The first two digits indicate the upright height in feet (MU6 = 6', MU7 = 7', MU8 = 8', MU10 = 10', MU12 = 12'). The last two digits indicate the base length in inches (33, 45, or 57).

Base length determines compatible arm lengths. Select the base length based on the arm length you need for your load, not the upright height alone.

♦ 33" base: compatible with 12", 18", and 24" arms. For shorter reach applications with narrower load widths.

♦ 45" base: compatible with 30" and 36" arms. For medium-reach applications and loads of moderate width.

♦ 57" base: compatible with 42" and 48" arms. For the longest reach in the Series 1000 system, suited to wider or longer loads.

Upright height determines storage capacity and ceiling clearance. Taller uprights accommodate more arm levels and allow higher stack storage, but require greater ceiling clearance. Verify ceiling height before ordering 10' or 12' uprights.

To build a starter unit (one complete bay), order two uprights, the appropriate arms, and a brace set. To extend a row with an add-on unit, order one upright, arms, and a brace set. Arms and brace sets are available separately on the MECO Series 1000 components pages.

Need help configuring a complete system? Call 866-333-0728 or use the quote form.

Where Series 1000 Medium Duty Uprights Are Commonly Used:

♦ Expanding existing Series 1000 installations: Adding uprights to extend a row that has reached capacity without purchasing a full starter unit when the system is already in place.

♦ Custom row configurations: Building a rack layout with a specific number of bays or bay spacing that does not match the standard starter/add-on unit counts.

♦ Replacement uprights: Replacing damaged uprights in an existing Series 1000 system without replacing the entire rack section.

♦ Maintenance departments and tool rooms: Configuring storage for pipe, conduit, bar stock, or tubing in utility areas where a complete starter kit may be more than the space requires.

Prices are shown by manufacturer model number.
Compare the exact same item across competitors - no extra searching.

Model Number Upright Height Length of Base Compatible Arms Available Separately Price View Model
6'-0" high
33" long
12", 18" and 24"
$225.95
6'-0" high
45" long
30" and 36"
$242.00
6'-0" high
57" long
42" and 48"
$266.00
7'-0" high
33" long
12", 18" and 24"
$240.00
7'-0" high
45" long
30" and 36"
$258.00
7'-0" high
57" long
42" and 48"
$281.00
8'-0" high
33" long
12", 18" and 24"
$255.00
8'-0" high
45" long
30" and 36"
$273.00
8'-0" high
57" long
42" and 48"
$296.00
10'-0" high
33" long
12", 18" and 24"
$286.00
10'-0" high
45" long
30" and 36"
$304.00
10'-0" high
57" long
42" and 48"
$327.00
12-0" high
33" long
12", 18" and 48"
$330.00
12-0" high
45" long
30" and 36"
$348.00
12-0" high
57" long
42" and 48"
$373.00

Frequently Asked Questions (FAQs)

What is MECO Series 1,000 medium duty cantilever racking used for?
MECO Series 1,000 medium duty cantilever racking stores long, bulky items that do not fit well on standard pallet racks. It supports materials like lumber, pipe, tubing, bar stock, and other products with uneven lengths. The open-front design allows workers to load and unload items without front columns getting in the way. That makes it a practical storage system for warehouses, shops, and industrial facilities.
How does MECO Series 1,000 cantilever racking help a facility run better?
This cantilever racking helps facilities organize long materials in a safer and more efficient way. It keeps inventory off the floor, reducing clutter and opening up valuable working space. A better-organized system also helps workers find, pick, and restock items more quickly. Over time, that can improve flow in storage areas and support cleaner daily operations.
What are the key features of MECO Series 1,000 medium duty cantilever racking?
MECO Series 1,000 medium-duty cantilever racking uses upright columns and arms to support long loads with clear access from the front. Many layouts include starter units to begin a row and add-on units to expand storage capacity. The system can often be configured with straight arms or inclined arms, depending on the material being stored. This flexibility helps facilities match the rack layout to product size, weight, and handling needs.
What types of facilities commonly use medium duty cantilever racking?
Medium-duty cantilever racking is common in warehouses, manufacturing plants, distribution centers, and maintenance departments. It is also useful in lumber yards, metal shops, and backroom storage areas with long inventory. Facilities choose it when products are difficult to stack safely on shelves or pallets. It works especially well for operations that need fast access to materials of different lengths.
Why choose MECO Series 1,000 cantilever racking for long material storage?
MECO Series 1,000 cantilever racking gives facilities a structured way to store long inventory without wasting floor space. Its design enhances visibility, helping teams check stock levels and locate materials faster. It also allows facilities to build rows that fit current demand and expand later as storage needs change. For many operations, this creates a more orderly storage area and supports safer material handling.
